Certus-NX System-on-Module
PR-CTNX-SOM
Ultra-compact Certus-NX module with PCIe Gen2, Gigabit SERDES and instant-on configuration for size-constrained designs.
Add this part to your quote list to request several line items together, or send the ordering code directly and we will confirm the available lot, packaging and date code.
Key specifications
| Device | Lattice Certus-NX-40 |
|---|---|
| LUTs | 39K |
| SERDES | PCIe Gen2, 1.25 Gb/s |
| Memory | HyperRAM 64 Mb |
| Configuration | Instant-on, single supply |
| Size | 45 × 32 mm |
Small, instant-on, secure
Certus-NX boots in milliseconds and needs a single supply rail, which simplifies power design in add-in cards and platform-management roles. The module footprint leaves most of a small carrier board free for application circuitry.
