ECP5 Evaluation Board
PR-ECP5-EV
Low-power ECP5 evaluation platform with SERDES, DDR3 and open-source toolchain support for cost-sensitive designs.
Add this part to your quote list to request several line items together, or send the ordering code directly and we will confirm the available lot, packaging and date code.
Key specifications
| Device | Lattice ECP5-5G (LFE5UM5G-85) |
|---|---|
| LUTs | 84K |
| SERDES | 4 × 5 Gb/s |
| Memory | DDR3-1600, 128 Mb flash |
| Toolchain | Radiant / open-source flow |
| Power | USB-C powered, < 2 W typical |
Low power, low cost
The ECP5 family is the workhorse for designs where power and unit cost matter more than raw logic density. This board exposes the SERDES lanes and the full IO bank so you can validate your bridging logic on real silicon.
- Four 5 Gb/s SERDES channels for PCIe Gen2, SGMII or DisplayPort
- Radiant toolchain support plus a fully open-source build flow
- Under 2 W typical draw — suitable for bus-powered and sealed enclosures
