Zynq UltraScale+ MPSoC Development Board
PR-XZU7EV-B
Full-featured ZU7EV development board with 4K video pipeline, dual DDR4 banks and FMC HPC expansion for machine-vision and embedded-vision prototyping.
Add this part to your quote list to request several line items together, or send the ordering code directly and we will confirm the available lot, packaging and date code.
Key specifications
| Device | AMD Xilinx ZU7EV (Quad Cortex-A53 + dual Cortex-R5F) |
|---|---|
| Logic cells | 504K |
| Memory | 2 × 4 GB DDR4-2400, 8 GB eMMC |
| Video | HDMI 2.0 in/out, DisplayPort 1.4 |
| Expansion | FMC-HPC, 2 × PMOD, PCIe Gen3 x4 |
| Networking | 1 GbE, USB 3.0 OTG |
Built for vision pipelines
The PR-XZU7EV-B brings a Zynq UltraScale+ EV-class MPSoC onto a board that is ready for camera-in, display-out development. Two independent DDR4-2400 channels keep the programmable logic and the processing system fed independently, so frame buffers and inference tensors no longer compete for one memory controller.
- Quad-core Arm Cortex-A53 application processor plus dual Cortex-R5F real-time cores
- Mali-400 MP2 GPU and VCU video codec unit for H.264/H.265 encode and decode
- 16 GTY transceiver lanes routed to FMC-HPC for 10/25 GbE, JESD204B and PCIe
- On-board JTAG, system controller and power sequencing with current telemetry
Development support
Reference designs for the ISP pipeline, 4K HDMI pass-through and a Linux BSP with the Xilinx Vitis flow are available on request. Our engineering team can port a customer IP block onto the board and return a validated boot image.
Ordering
Supplied as a board-only part or as a bundle with power supply, USB cable, 32 GB SD card and thermal solution. Volume and OEM configurations are quoted per project.
Typical applications
Ordering information
- Supplied in original manufacturer packaging unless otherwise agreed in writing.
- Lot, date code and packaging option are confirmed on the quotation for each line.
- Minimum order quantity may apply to low-volume order codes — ask if you are unsure.
- Volume, OEM and scheduled-release pricing available on request.
Quality assurance
Every incoming lot passes our standard inspection protocol before it is offered for sale:
- Documentation and traceability review against the approved source
- Visual inspection of marking, packaging and lead condition
- X-ray or decapsulation where authenticity cannot be established externally
- Electrical verification on request, quoted per line
Inspection evidence is retained against the lot number and can be supplied with the shipment when your process requires it.
Shipping & returns
- Worldwide dispatch with tracking; express courier available for urgent lines.
- Counterfeit parts are refunded in full, including freight, per our published policy.
Design-in support
Our engineering team supports the parts we supply. That includes pin-out and power questions, device selection against an existing design, and bringing up reference designs on the hardware you buy from us.
- Device and package selection against cost, power and IO requirements
- Carrier board and thermal design review for module-based designs
- Cross-reference and second-source proposals for allocation-constrained parts
- Toolchain setup guidance for AMD, Altera, Lattice, Microchip and Efinix flows
Send us your requirement
Describe the application, the interfaces and the environment. We reply with a shortlist of suitable parts and their availability.
